| Part Number | Dimension (mm) | Package | Application | Frequency | Insertion Loss | Return Loss | Attenuation |
| L | W | T | MHz | dB (@ +25℃) | dB (@ -40℃~+85℃) | dB | dB |
| FLT18B2425D-1124A | 1.6 | 0.8 | 0.60 | DIP | WIFI | 2400-2500 | 1.4 max.(1.1 typ) | 1.6 max. | 10 min. | 20 min. @ 500-960 MHz
23 min. @ 3200 MHz
30 min. @ 4800-5000 MHz
32 min. @ 7200-7500 MHz |
| FLT18B5159L-1183Q | 1.6 | 0.8 | 0.6 | LGA | WIFI | 5150-5950 | 0.6 max.(0.5 typ) | 0.9 max. | 10 min. | 40 min. (43 typ.) @ 30-2700 MHz
12 min. (22 typ.) @ 7250-7800 MHz
20 min. (25 typ.) @ 10300-11700 MHz |
| FLT18B5159L-1187A | 1.6 | 0.8 | 0.60 | LGA | WIFI | 5150-5950 | 0.6 max.(0.5 typ) | 0.9 max. | 13 min. | 35 min. @ 2400-2500 MHz
30 min. @ 10300-11900 MHz
25 min. @ 15450-17850 MHz |
| FLT18B5159L-1196B | 1.6 | 0.8 | 0.6 | LGA | WIFI | 5150-5950 | 1.0 max.(0.8 typ) | 1.2 max. | 17 typ.
10 min. | 35 min. @ 30-2700 MHz
35 min. @ 3400-3800 MHz
20 min. @ 6900 MHz
20 min. @ 7250-7800 MHz
20 min. @ 10300-11900 MHz |
| FLT18B5171L-1189A | 1.6 | 0.8 | 0.60 | LGA | WIFI | 5150-7125 | 1.0 max.(0.7 typ) | 1.2 max. | 10 min. | 35 min. (45 typ). @ 2400-2500 MHz
25 min. (34 typ). @ 10340-14250 MHz
20 min. (30 typ). @ 15510-21375 MHz |
| FLT18B5172L-1190A | 1.6 | 0.8 | 0.60 | LGA | WIFI | 5150-5710
5710-5925
5925-6425
6425-7125
7125-7250 | 1.24 typ. 1.7 max.
0.71 typ. 1.0 max.
0.61 typ. 1.0 max.
0.73 typ. 1.2 max.
0.78 typ. 1.3 max. | 1.9 max. | 10 min. | 40 min. (42 typ). @ 100-2690 MHz
40 min. (42 typ). @ 3300-3800 MHz
20 min. (41 typ). @ 3800-4200 MHz
5 min. (14 typ). @ 4500-4600 MHz
24 min. (34 typ). @ 9000-9200 MHz
30 min. (42 typ). @ 9600-9800 MHz
30 min. (40 typ). @ 10300-11850 MHz
20 min. (34 typ). @ 11850-14250 MHz |
| FLT21B2425D-2125A | 2.0 | 1.2 | 0.90 | DIP | WIFI | 2400-2500 | 2.5 max.(2.3 typ) | 2.8 max. | 10 min. | 40 min. @ 880-960 MHz
40 min. @ 1710-1990 MHz
20 min. @ 2110-2170 MHz
30 min. @ 4800-5000 MHz
30 min. @ 7200-7500 MHz |
| FLT21B2425L-2124A | 2.0 | 1.25 | 1.00 | LGA | WIFI | 2400-2500 | 1.25 max.(1.1 typ) | 1.45 max. | 15 typ.
12 min. | 30 min. (37 typ) @ 500~950 MHz
25 min. (40 typ) @ 1500~1650 MHz
19 min. (26 typ) @ 3200~3300 MHz
39 min. (57 typ) @ 4800~5000 MHz
34 min. (38 typ) @ 7200~7500 MHz |
| FLT45B5158D-1156A | 4.5 | 3.2 | 2.20 | DIP | WIFI | 5150-5815
5815-5825
5825-5835
5835-5850 | 2.8 max.
3.0 max.
3.1 max.
3.3 max. |
| 9.5 min. | 30 min. @ 30-1935 MHz
30 min. @ 2400-2500 MHz
15 min. @ 3453-3870 MHz
4 min. @ 5935 MHz
50 min. @ 6100-7250 MHz
45 min. @ 7250-7740 MHz
36 min. @ 10360-11610 MHz
10 min. @ 15540-17415 MHz |
| FLT45B6171D-1166A | 4.5 | 3.2 | 2.20 | DIP | WIFI | 6100-7125 | 2.8 max. |
| 9.5 min. | 35 min. @ 30~2370 MHz
35 min. @ 2400~2500 MHz
33 min. @ 3960~4740 MHz
35 min. @ 4740~5150 MHz
50 min. @ 5170~5815 MHz
45 min. @ 5815~5825 MHz
30 min. @ 5825~5850 MHz
15 min. @ 5900~5925 MHz
3 min. @ 7925~8250 MHz
6 min. @ 8250~9440 MHz
30 min. @ 11890~14210 MHz
10 min. @ 17385~21315 MHz |
